| Video |
|---|
| Imaging Device |
1/3" 4MP CMOS |
| Resolution |
2560x1440 |
| Max. Framerate |
30fps@4M(N), 25fps@4M(P) |
| Min. Illumination |
Color: 0.27Lux(F2.0, 1/30sec)
BW: 0Lux(IR LED on) |
| Video Out |
BNC(AHD), additional CVBS for installation(2Pin connector type) |
| Video Transmission Distance |
500m(5C2V Coaxial Cable) |
| Lens |
|---|
| Focal Length (Zoom Ratio) |
6.0mm fixed |
| Max. Aperture Ratio |
F2.0 |
| Angular Field of View |
H: 49.02°, V: 27.61°, D: 55.60° |
| Min. Object Distance |
0.5m(1.64ft) |
| Pan / Tilt / Rotate |
|---|
| Pan / Tilt / Rotate Range |
0°~350° / 0°~67° / 0°~355° |
| Operational |
|---|
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
UserBLC, HLC, DWDR |
| Digital Noise Reduction |
2DDNR |
| Motion Detection |
4 zones |
| Privacy Masking |
2 zones |
| Gain Control |
Low / Middle / High / Very High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed |
1/30 ~ 1/12,000sec(N), 1/25~ 1/12,000sec(P) |
| Video Rotation |
H-Rev/V-Rev |
| Analytics |
Motion detection |
| IR Viewable Length |
30m(98.43ft) |
| Coaxial Protocol |
ACP(AHD Coax Protocol), CVBS: Pelco-C(Coaxitron) |
| Environmental & Electrical |
|---|
| Operating Temperature / Humidity |
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
| Input Voltage |
12VDC |
| Power Consumption |
Max 5W |
| Mechanical |
|---|
| Color / Material |
Ivory / Plastic |
| Product Dimensions / Weight |
Ø110.1 x 86.1mm(Ø4.33”x3.39”), 240g(0.53 lb) |
