Product Specification

• Video
  Imaging Device		1/3" 4MP CMOS
  Resolution		2560x1440
  Max. Framerate		30fps@4M(N), 25fps@4M(P)
  Min. Illumination		Color: 0.16Lux(F1.6, 1/30sec) BW: 0Lux(IR LED on)
  Video Out		BNC(AHD), additional CVBS for installation(2Pin connector type)
  Video Transmission Distance		500m(5C2V Coaxial Cable)
  Lens
  Focal Length (Zoom Ratio)		3.2~10mm(3.1x) manual varifocal
  Max. Aperture Ratio		F1.6
  Angular Field of View		H: 93.48°(Wide)~29.44°(Tele), V: 50.47°(Wide)~16.64°(Tele), D: 112.53°(Wide)~33.7°(Tele)
  Min. Object Distance		0.5m(1.64ft)
  Focus Control		Manual
  Lens Type		DC auto iris
  Operational
  Day & Night		Auto(ICR)
  Backlight Compensation		UserBLC, HLC, DWDR
  Digital Noise Reduction		2DDNR
  Motion Detection		4 zones
  Privacy Masking		2 zones
  Gain Control		Low / Middle / High / Very High
  White Balance		ATW / AWC / Manual / Indoor / Outdoor
  Electronic Shutter Speed		1/30 ~ 1/12,000sec(N), 1/25~ 1/12,000sec(P)
  Video Rotation		H-Rev/V-Rev
  Analytics		Motion detection
  Alarm I/O		MD Output 1ea
  IR Viewable Length		30m(98.43ft)
  Coaxial Protocol		ACP(AHD Coax Protocol), CVBS: Pelco-C(Coaxitron)
  Environmental & Electrical
  Operating Temperature / Humidity		-30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH * Start up should be done at above -10°C
  Certification		IP66, IK10
  Input Voltage		24VAC, 12VDC
  Power Consumption		Max 5.8W
  Mechanical
  Color / Material		Dark Grey / Aluminum
  Product Dimensions / Weight		Ø78.0x259.8mm(Ø3.07”x10.23”), 914g(2.02 lb)

• • Design and specifications are subject to change without notice.
  • Wisenet is the proprietary brand of Hanwha Techwin, formerly known as Samsung Techwin.
