Product Specification

• Video
  Imaging Device		1/2.8" CMOS x 3CH
  Resolution		1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
  Max. Framerate		H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz)
  Min. Illumination		Color: 0.04lux(F2.2, 1/30sec) BW: 0.004lux(F2.2, 1/30sec)
  Video Out		CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
  Lens
  Focal Length (Zoom Ratio)		3~6mm(2x) motorized varifocal
  Max. Aperture Ratio		F2.2(Wide)-F3.1(Tele)
  Angular Field of View		H: 107˚(Wide)~56.3˚(Tele) / V: 57˚(Wide)~31.5˚(Tele) / D: 126˚(Wide)~64.3˚(Tele)
  Min. Object Distance		0.5m(1.64ft)
  Focus Control		Simple focus
  Lens Type		Fixed iris
  Pan / Tilt / Rotate
  Pan / Tilt / Rotate Range		0~360˚ / 0~73˚ / 0~90˚
  Operational
  Camera Title		Displayed up to 85 characters
  Day & Night		Auto(ICR)
  Backlight Compensation		BLC, HLC, WDR, SSDR
  Wide Dynamic Range		extreme WDR(150dB)
  Digital Noise Reduction		SSNRⅤ
  Digital Image Stabilization		Support
  Defog		Support
  Motion Detection		8ea, 8point polygonal zones
  Privacy Masking		32ea, polygonal zones - Color: Grey, Green, Red, Blue, Black, White - Mosaic
  Gain Control		Low / Middle / High
  White Balance		ATW / AWC / Manual / Indoor / Outdoor
  LDC		Support
  Electronic Shutter Speed		Minimum / Maximum / Anti flicker (2~1/12,000sec)
  Video Rotation		Flip, Mirror
  Analytics		Defocus detection, Directional detection,Motion detection, Enter/Exit,Tampering, Virtual line
  Alarm Triggers		Analytics, Network disconnect
  Alarm Events		File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC at event triggers Handover
  Network
  Ethernet		Metal shielded RJ-45(10/100/1000BASE-T)
  Video Compression		H.265/H.264: Main/Baseline/High, MJPEG
  Smart Codec		Manual(5ea area), WiseStreamⅡ
  Bitrate Control		H.264/H.265: CBR or VBR MJPEG: VBR
  Streaming		Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles)
  Protocol		IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP
  Security		HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device Certificate(Hanwha Techwin Root CA)
  Application Programming Interface		ONVIF Profile S/G/T SUNAPI(HTTP API)
  General
  Webpage Language		English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
  Edge Storage		Micro SD/SDHC/SDXC 2slot 512GB(256GBx2)
  Memory		4GB RAM, 512MB Flash
  Environmental & Electrical
  Operating Temperature / Humidity		Normal : -40°C~+55°(-40°F ~ +131°F) / Intermittent : -40°C~+60°C(-40°F ~ +140°F) Less than 95% RH(Non condensing)
  Storage Temperature / Humidity		-50°C~+60°C(-58°F~+140°F) / Less than 90% RH
  Certification		IP66, IK10, NEMA4X
  Input Voltage		PoE+
  Power Consumption		Max : 16.5W, Typical : 8.2W
  Mechanical
  Color / Material		White / Aluminum
  RAL Code		RAL9003
  Product Dimensions / Weight		Ø251x116.5mm / 3Kg
  DORI (EN62676-4 standard)
  Detect (25PPM/ 8PPF)		Wide: 28.4m(11.18ft) / Tele: 71.8m(28.27ft)
  Observe (63PPM/ 19PPF)		Wide: 11.4m(4.49)ft) / Tele: 28.7m(11.30ft)
  Recognize (125PPM/ 38PPF)		Wide: 5.7m(2.24ft) / Tele: 14.4m(5.67ft)
  Identify (250PPM/ 76PPF)		Wide: 2.8m(1.10)ft) / Tele: 7.8m(3.07ft)

• •
