Hanwha Techwin QNF-9010 12MP IP Indoor Fisheye Security Camera 1.08mm Fixed Lens

Hanwha Techwin QNF-9010 12MP IP Indoor Fisheye Security Camera 1.08mm Fixed Lens

QNF-9010

$950.00 USD
$950.00 USD
Sale Sold out
Shipping calculated at checkout.

Hanwha Techwin QNF-9010 Wisenet Q series network Indoor fisheye dome Security camera

QNF-9010

Q Series 12 MP Sensor 360° Indoor Fisheye Camera

  • 12 MP image sensor, 3008 x 3008 resolution output, 30fps
  • Fisheye lens 1.08mm (187°X187°)
  • Original fisheye view, onboard dewarding to Single panorama, Double panorama, Quad view
  • Lens rotation & analog video output for easy installation and adjustment
  • Triple Codec: H.265, H.264 and MJPEG multiple streaming
  • WiseStream II compression technology
  • WDR 120dB
  • Defocus, Tampering, motion detection
  • Heatmap, people counting business intelligence
  • SD card slot
  • IP42 rated, PoE powered
  • White camera body

Video
Imaging Device 1/2.3" 12M CMOS
Effective Pixels 3008(H) x 3008(V)
NETD None
Pixel Size None
Min. Illumination Color: 0.39 Lux (F2.2, 1/30sec)
Video Out CVBS : 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P), for Installation
Lens
Focal Length (Zoom Ratio) 1.08mm fixed focal
Max. Aperture Ratio F2.2
Angular Field of View H: 187° / V: 187° / D: 187°
Min. Object Distance 0.5m(1.64ft)
Focus Control None
Lens Type None
Mount Type None
Optional Lens None
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range None
Pan Range None
Pan Speed None
Tilt Range None
Tilt Speed None
Rotate Range None
Sequence None
Preset Accuracy None
Azimuth None
Auto Tracking None
Operational
IR Viewable Length None
Camera Title Displayed up to 85 characters
Day & Night Auto(Electrical)
Backlight Compensation BLC, WDR, SSDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNRⅤ
Digital Image Stabilization None
Defog None
Motion Detection 4ea, polygonal zones
Privacy Masking 6ea, Rectangle zones
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC None
Electronic Shutter Speed Minimum / Maximum / Anti flicker (2~1/12,000sec)
Digital PTZ Support(Preset, Group)
Video Rotation Flip, Mirror
Analytics Defocus detection, Motion detection, Tampering
Business Intelligence People counting, Heatmap
Serial Interface None
Alarm I/O None
Alarm Triggers Analytics, Network disconnect
Alarm Events File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers
Audio In None
Audio Out None
IR Illuminator (Optional) None
Wiper None
Coaxial Protocol None
Video Transmission Distance None
Radiometry
Temperature detect range None
Temperature accuracy None
Temperature detection None
Additional None
Network
Ethernet RJ-45(10/100BASE-T)
Video Compression H.265/H.264: Main/High, MJPEG
Resolution Overview : 3008x3008, 640x640 Double panorama: 2560x1280, 1920x960, 1280x640, 1024x512, 640x320 Single panorama: 3200x800, 2560x640, 1920x480, 1280x320, 1024x256 Quad view: 2560x1920, 1920x1440, 1280x960, 1024x768, 640x480
Max. Framerate H.265/H.264: Overview-Max. 30fps/25fps@3008x3008(60Hz/50Hz), Double panorama-Max. 28fps/25fps@2560x1280(60Hz/50Hz) Single panorama-Max. 28fps/25fps@3200x800(60Hz/50Hz) MJPEG: Max. 5fps(60Hz/50Hz)
Smart Codec Manual(5ea area), WiseStreamⅡ
Video Quality Adjustment H.264/H.265: Target bitrate level control MJPEG: Quality level control
Bitrate Control H.264/H.265: CBR or VBR MJPEG: VBR
Streaming Unicast(6 users) / Multicast Multiple streaming(Up to 3 profiles)
Audio Compression None
Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour
Security HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device Certificate(Hanwha Techwin Root CA)
Edge Storage Micro SD/SDHC/SDXC 1slot 256GB
Application Programming Interface ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform
Webpage Language English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Web Viewer Supported OS: Windows 7, 8.1, 10, Mac OS X 10.12, 10.13, 10.14 Recommended Browser: Google Chrome Supported Browser : MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only)
Memory 2048MB RAM, 256MB Flash
Environmental
Operating Temperature / Humidity -10°C ~ +40°C(+14°F ~ +104°F) / Less than 90% RH
Storage Temperature / Humidity -50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH
Certification IP42
Electrical
Input Voltage PoE(IEEE802.3af, Class3)
Power Consumption PoE: Max 7.7W, typical 6.4W
Mechanical
Color / Material White / Plastic
RAL Code RAL9003
Product dimensions / weight Ø99x49mm, 370g
Conduit hole
Hanging mount(Dome)
Skin cover(Dome)
Weather cap(Dome)
Power module
Backbox
DORI
Detect (25PPM/ 8PPF) 34.9m(114.49ft)
Observe (63PPM/ 19PPF) 13.9m(45.60ft)
Recognize (125PPM/ 38PPF) 7.0m(22.96ft)
Identify (250PPM/ 76PPF) 3.5m(11.48ft)
