| Operational |
|---|
| Alarm I/O |
Configurable 4 Ports
12 V DC output, max load 50 mA |
| Audio In |
Selectable(mic in/line in) |
| Audio Out |
Line out, Max.output level: 1Vrms |
| Network |
|---|
| Ethernet |
RJ-45(10/100BASE-T) |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, ICMP, ARP, DNS, LLDP |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Device Certificate(Hanwha Techwin Root CA) |
| Application Programming Interface |
SUNAPI(HTTP API) |
| General |
|---|
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Web Viewer |
Support |
| Memory |
4GB RAM, Flash 256MB |
| Environmental & Electrical |
|---|
| Operating Temperature / Humidity |
-40°C~+60°C(-40°F ~ +140°F) / Less than 95% RH(Non-condensing)
Start up should be done at above -30°C |
| Storage Temperature / Humidity |
-50°C~+60°C (-58°F~+140°F) / Less than 95% RH(Non-condensing) |
| Input Voltage |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
Max. 4.5W |
| Mechanical |
|---|
| Color / Material |
White |
| RAL Code |
RAL9003 |
| Product dimensions / weight |
143mm x 73mm x 27.3mm / 171g |
