Product Spec

• Display
  Network camera
  	Inputs	Max. 32CH
  	Resolution	12MP ~ CIF
  	Protocols	Wisenet, ONVIF
  Decoding
  	Local Display	[Dual Display] HDMI: 3840 x 2160, 1920x1080, 1280x720 VGA: 1920x1080, 1280x720
  	Multi Screen Display	[Local Monitor] 1 / 2V / 3V / 4 / 9 / 16 Sequence [Web] 1 / 4 / 9 / 16 / 4 / Sequence
  	Resolution	12M(30fps), 8.3M(120fps), 1080p(480fps), 720P(960fps), D1(1560fps)
  Performance
  Operating System
  	Embedded	Linux
  Record
  	Compression	H.265, H.264, MJPEG
  	Recording Bandwidth	Max. 256Mbps
  	Resolution	12MP ~ CIF
  	Mode	Normal, Schedule(Continuous/Event), Event (Pre/Post)
  	Event Trigger	Alarm Input, Video Loss, Camera Event(Alarm, MD, Video Analytics, Defocus)
  	Event Action	e-Mail, PTZ Preset, Alarm Out, Buzzer, Monitor Out
  Search & Play
  	Playback Bandwidth	Max. 32Mbps(16CH simultaneously)
  	User	Max. 4 Users (Local 1, Remote 3)
  	Simultaneous playback	Max. 16CH(Local Monitor, Network)
  	Fisheye Dewarping	WEB / CMS
  	Mode	Date & Time(Calendar), Event Log list, Text Search, Smart Search
  	Resolution	12MP ~ CIF
  	Playback Control	Fast/Slow Forward / Backward, Move one step Up / Down
  Storage
  	Supported HDD	Up to 6TB
  	HDD Slot	SATA 8ea(Max. 48TB)
  	External	iSCSI storage(Max. 384TB)
  Backup
  	File backup	BU/Exe(GUI), JPG/AVI(Network)
  	Function	Multi channel(Upto 4CH) Play, Date-Time/Title display
  Network
  Protocol		IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client)
  DDNS		Wisenet DDNS
  Audio
  	Input/Output	32 CH(network)
  	Compression	G.711, G.726, AAC(16/48KHz)
  	Audio Communication	2-Way
  Max Remote Users		Search(3), Live Unicast(10), Multicast(20)
  Security		IP address filtering, User access Log, 802.1x, Encryption
  Web viewer
  	Supported OS	Windows 7, 8, 10, Mac OS X 10.9. 10.10. 10.11
  	Supported browser	MS IE, Google Chrome, Mac Safari, Firefox
  Viewer Software		SSM, Webviewer, Smart Viewer, Wisenet mobile Support SDK/CGI(SUNAPI) for integration to 3'rd party VMS
  Functions
  Camera Setup
  	Register	Auto, Manual
  	Item	IP address, Add profile edit, Bitrate, Compression, GOP, Quality, Camera MD setup Camera video setup (Simple focus, Brightness/Contrast, Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter, SSDR, DIS), Fisheye Dewarping Mode, Hallway View Setup, Camera Webpage
  PTZ
  	Control	Via GUI, Webviewer, SPC-2000
  	Preset	255 Presets
  Smart phone
  	Support Model	iOS, Android
  	Protocol Support	RTP, RTSP, HTTP, CGI(SUNAPI)
  	Control	Live(Multi-Profile Support), Playback
  	Max. Remote Users	Search(3), Live Unicast(10)
  Redundancy
  	Failover	N+1
  	ARB	Support
  Easy configuration		P2P(QR code)
  Interface
  Front
  	Indicator	OK
  HDMI		1EA
  VGA		1EA
  e-SATA		1EA
  Audio		Out(1EA, RCA, Line)
  Ethernet		RJ-45(10/100/1000BASE-T) x 2
  Alarm		In 8EA, Out 4EA
  USB		2EA(Front 1, Rear 1)
  Serial(Protocols)		RS-232C
  Power inlet		AC 1EA
  System
  Log
  	Log List	Max. 20,000 (System Log, Event Log each)
  System Control		Mouse, IR remocon, Web, Controller (SPC-2000)
  Language		English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai
  Environmental
  Operating Temperature		0°C to +40°C(32℉ to 104℉)
  Operating Humidity		20% ~ 85% RH
  Electrical
  Power Input		100~240VAC±10%
  Power Consumption		Max. 99W(6TB 8EA)
  Mechanical
  Color / Material		Black / Metal
  Dimension (WxHxD)		440.0 x 88.0 x 384.8mm (17.32" x 3.46" x 15.15") (2U)
  Weight		5.38Kg
