Product Spec

• Video
  Imaging Device		1/1.7" 12M CMOS
  Min. Illumination		Color: 0.3Lux(F2.2, 1/30sec) BW : 0Lux(IR LED on)
  Video Out		CVBS : 1.0 Vp-p / 75Ω composite, 714x480(N), 702x576(P), for Installation
  Lens
  Focal Length (Zoom Ratio)		2.1mm fixed focal
  Max. Aperture Ratio		F2.2
  Angular Field of View		H: 180° / V: 180° / D: 180°
  Min. Object Distance		0.5m(1.64ft)
  Focus Control		Simple focus
  Operational
  Camera Title		Displayed up to 60 characters
  Day & Night		Auto(ICR)
  Backlight Compensation		BLC, WDR
  Wide Dynamic Range		120dB
  Digital Noise Reduction		SSNR
  Defog		Support
  Motion Detection		8ea, 8point polygonal zones
  Privacy Masking		8ea, polygonal zones - Color: Grey/Green/Red/Blue/Black/White
  Gain Control		Low / Middle / High
  White Balance		ATW / AWC / Manual / Indoor / Outdoor
  Electronic Shutter Speed		Minimum / Maximum / Anti flicker
  Video Rotation		Flip, Mirror
  Analytics		Defocus detection, Motion detection, Appear/Disappear, Enter/Exit, Tampering, Virtual line, Audio detection
  Business Intelligence		People counting, Heatmap
  Alarm I/O		Input 1ea / Output 1ea
  Alarm Triggers		Analytics, Network disconnect, Alarm input
  Alarm Events		File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output
  Audio In		Selectable(mic in/line in/built-in mic) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
  Audio Out		Line out, Max.output level: 1Vrms
  IR Viewable Length		15m(49.21ft)
  Network
  Ethernet		RJ-45(10/100BASE-T)
  Video Compression		H.265/H.264: Main/Baseline/High, MJPEG
  Smart Codec		Manual(5ea area), WiseStreamⅠ
  Bitrate Control		H.264/H.265: CBR or VBR MJPEG: VBR
  Streaming		Multiple streaming(Up to 3 profiles)
  Protocol		IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
  Security		HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP)
  Application Programming Interface		ONVIF Profile S/G SUNAPI(HTTP API) Wisenet open platform
  Environmental & Electrical
  Operating Temperature / Humidity		-10°C ~ +55°C(+14°F ~ +131°F) / Less than 90% RH
  Storage Temperature / Humidity		-30°C ~ +60°C(-22°F ~ +140°F) / Less than 90% RH
  Certification		IK10 EN55011:2009+A1:2010, EN50581:2012, EN50121-3-2:2015, EN61000-4-2:2009, EN61000-4-3:2006+A2:2010, EN61000-4-4:2012, EN61000-4-5:2014, EN61000-4-6:2009
  Mechanical
  Color / Material		Ivory / Plastic
  Product dimensions / weight		Ø146x63.4mm(Ø5.75x2.5"), 805g(1.77 lb)
