Samsung Hanwha Techwin WiseNet P Series PNM-9000VQ Outdoor NW Quad Dome Camera

Samsung Hanwha Techwin WiseNet P Series PNM-9000VQ Outdoor NW Quad Dome Camera

PNM-9000VQ

$1,700.00 USD
$1,700.00 USD
Sale Sold out
Shipping calculated at checkout.

PNM-9000VQ

4x 2MP / 5MP Multi-sensor Multi-directional camera
Network vandal outdoor Multi-sensor Multi-Directional dome camera, (2MP/5MP X 4 sensors) 8MP ~20MP (2MP @ 60fps or 5MP @30fps), fixed focal lens modules, triple codec H.265/H.264/MJPEG with WiseStream II technology, 150dB WDR @ 2MP or 120dB @ 5MP, defocus detection, built in analytics, 4x SD card, hallway view, HLC, fog detection, DIS(Gyro Sensor), PoE+, IP66/IK10, -40°C ~ +55°C (-40°F ~ +131°F)


Key Features:

  • Exchangeable 4ea x 2MP / 5MP lens modules 8MP to 20MP resolution depend on the combination of lens modules
  • 60fps@2MP, 30fps@5MP (H.265 / H.264)
  • WDR 150dB with 2MP lens module, 120dB with 5MP lens module
  • 2.4mm, 2.8mm, 3.6mm, 6mm fixed lens (2MP module)
  • 3.7mm, 4.6mm, 7mm fixed lens (5MP module)
  • H.265, H.264, MJPEG codec, Multi streaming support
  • Video analytics, WiseStream Ⅱ
  • IP66, IK10, SD / SDHC / SDXC memory 4 slots
  • Lens modules are required, not included with the camera





Samsung Hanwha Techwin PNM-9000VQ Specs

Camera
Zoom Digital: 24x
IR Cut Filter Digital
Day/Night Yes
Shutter Speed 1/12,000 to 2 Seconds
Video
Streaming Resolution 2560 x 1920 at 30 fps
1920 x 1080 at 60 fps
Supported Video Compression H.264, H.265, MJPEG
Multi-View Streaming Yes, 10 Streams
Networking
Security Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, User Access Log
Supported Protocols ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, ONVIF Profile S, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP, UPnP
System Integration
Application Programming Interface (API) SUNAPI (HTTP API)
Analytics Tampering, Loitering, Directional Detection, Fog Detection, Virtual Line, Enter, Exit, Appear, Disappear, Face Detection, Motion Detection, and Defocus Detection
Event Trigger Yes
Event Action Recording, Notification, Alarm
System Requirements
Windows OS Support Windows 7, 8.1, 10
Mac OS Support macOS 10.12, OS X 10.11, OS X 10.10
Environmental
Operating Temperature -40 to 131°F / -40 to 55°C
Storage Temperature -58 to 140°F / -50 to 60°C
Operating Humidity 0 to 89%
IP Rating IP66
IK Rating IK10
General
Recording Media microSD (up to 1024 GB)
Pan/Tilt None
I/O Connections 1 x RJ45
Video Management Software SmartViewer, SSM
Supported Languages Czech
Dutch
English
French
German
Greek
Hungarian
Italian
Japanese
Korean
Polish
Portuguese
Russian
Spanish
Swedish
Traditional Chinese
Turkish
Certifications UL, as per Manufacturer
Internal Storage None
External Storage Options Local PC
Power Source PoE 802.3at (30 W)
Power Consumption 25.5 W
Material of Construction Metal (Unspecified Type)
Dimensions ø: 10.0 x H: 5.1" / ø: 253.0 x H: 130.0 mm
Weight 6.61 lb / 3 kg
