UNV 4MP IP67 NDAA Audio IP Network Uniview Surveillance Eyeball Security Camera
UNV 4MP IP67 NDAA Audio IP Network Uniview Surveillance Eyeball Security Camera
SKU:IPC3614SR3-ADF28K-G-BK
Couldn't load pickup availability
UNV 4MP IP67 PoE HD IR Outdoor Lighthunter Eyeball IP Uniview Security Camera with 2.8mm Fixed Lens with Night Vision
Uniview Lighthunter Turret Camera .
Secure high-definition surveillance with the Uniview 4MP PoE Eyeball Camera featuring a 2.8mm fixed lens, built-in mic, night vision, and IP67 weatherproof rating. This NDAA compliant Uniview IP camera ensures reliable performance for outdoor security needs.
Key Features of 4MP Uniview IP Camera:
- Compression : Ultra 265, H.265, H.264, MJPEG
- Megapixel: 4MP
- Camera Style: Eyeball
- Lens Type :Fixed Lens
- Lens Size : 2.8mm
- Protection Code : IP67
- Dimensions (Ø x H): Φ110.5 x 94.1mm (Φ4.4” x 3.7”)
- Weight:0.43kg (0.95lb)
- Environmental : outdoor
- Audio Support : Built-in Mic
Uniview 4MP IP67 PoE Eyeball Camera – Night Vision, Built-in Mic
Discover professional-grade surveillance with the UNV 4MP PoE Eyeball IP Camera from Secure IT Global. Engineered with LightHunter technology, this Uniview security camera delivers crystal-clear imaging even in low-light environments. Ideal for both residential and commercial use, it supports Ultra 265, H.265, H.264, and MJPEG compression standards for efficient video storage.
This Uniview 4MP IP camera features a 2.8mm fixed lens with a wide field of view, built-in microphone for audio capture, and IP67 weatherproof housing to ensure reliable outdoor performance. As a fully NDAA compliant camera, it's suitable for government and regulated industry applications.
Whether you're upgrading your system or installing new, this Uniview IP PoE camera is a trusted solution in the Unv security camera range. Compatible with ONVIF PoE camera systems, it integrates seamlessly into existing surveillance setups.
Specification of 4MP Uniview IP Camera :
Camera |
||||||||||
| Sensor | 1/3″, 4.0 megapixel, progressive scan, CMOS | |||||||||
| Lens | 2.8mm@F1.6 | |||||||||
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) | |||||
| 2.8 | 63.0 | 25.2 | 12.6 | 6.3 | ||||||
| Angle Of View (H) | 101.1° | 83.7° | ||||||||
| Angle Of View (V) | 55.3° | 44.9° | ||||||||
| Angle Of View (O) | 111.1° | 89.2° | ||||||||
| Adjustment angle | Pan: 0° ~ 360° | Tilt: 0° ~ 80° | Rotate: 0° ~ 360° | |||||||
| Shutter | Auto/Manual, 1 ~ 1/100000s | |||||||||
| Minimum Illumination | Support LightHunter: Colour: 0.003Lux ( F1.6, AGC ON) 0Lux with IR | |||||||||
| Day/Night | IR-cut filter with auto switch (ICR) | |||||||||
| Digital noise reduction | 2D/3D DNR | |||||||||
| S/N | >56dB | |||||||||
| IR Range | Up to 30m (98ft) IR range | |||||||||
| Wavelength | 850nm | |||||||||
| IR On/Off Control | Auto/Manual | |||||||||
| Defog | Digital Defog | |||||||||
| WDR | 120dB | |||||||||
Video |
||||||||||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | |||||||||
| H.264 Code Profile | Baseline profile, Main profile, High profile | |||||||||
| Frame Rate | Main Stream: 4MP (2688*1520), Max 25fps;4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
|||||||||
| Video Bit Rate | 128 Kbps~16 Mbps | |||||||||
| 9:16 Corridor Mode | Supported | |||||||||
| OSD | Up to 4 OSDs | |||||||||
| Privacy Mask | Up to 4 areas | |||||||||
| ROI | Up to 8 areas | |||||||||
| Motion Detection | Up to 4 areas | |||||||||
Image |
||||||||||
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | |||||||||
| Digital noise reduction | 2D/3D DNR | |||||||||
| Smart IR | Supported | |||||||||
| Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise | |||||||||
| Dewarping | N/A | |||||||||
| HLC | Supported | |||||||||
| BLC | Supported | |||||||||
Smart |
||||||||||
| Behavior Detection | Cross line, intrusion(based on human body detection) | |||||||||
| motion detection, tampering alarm, audio detection | ||||||||||
| General Function | Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication | |||||||||
Network |
||||||||||
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, 802.1x, SNMP | |||||||||
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API | |||||||||
| Client | EZStation EZView EZLive | |||||||||
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below | |||||||||
| Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ | ||||||||||
Audio |
||||||||||
| Audio Compression | G.711 | |||||||||
| Suppression | Supported | |||||||||
| Sampling Rate | 8KHZ | |||||||||
Storage |
||||||||||
| Edge Storage | Micro SD, up to 256 GB | |||||||||
| Network Storage | ANR,NAS(NFS) | |||||||||
Interface |
||||||||||
| Network | 10/100M Base-TX Ethernet | |||||||||
| Built-in Mic | Supported | |||||||||
Certifications |
||||||||||
| Certifications | UL: UL60950-1 FCC: FCC Part 15 | |||||||||
General |
||||||||||
| Power | DC 12V±25%, PoE (IEEE 802.3af) | |||||||||
| Power consumption: Max 6.0W | ||||||||||
| Dimensions (Ø x H) | Φ110.5 x 94.1mm (Φ4.4” x 3.7”) | |||||||||
| Net Weight | 0.43kg (0.95lb) | |||||||||
| Material | Metal | |||||||||
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | |||||||||
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | |||||||||
| Surge Protection | 2KV | |||||||||
| Ingress Protection | IP67 | |||||||||
| Reset Button | N/A | |||||||||
