UNV 8MP IP67 NDAA Audio IP Network Uniview Eyeball Security Surveillance Camera
UNV 8MP IP67 NDAA Audio IP Network Uniview Eyeball Security Surveillance Camera
SKU:IPC3618SR3-ADF28KM-G
Couldn't load pickup availability
UNV 8MP IP67 M12 Outdoor LightHunter HD IR Eyeball IP Uniview Security Camera 2.8mm Fixed Lens with Night Vision
Uniview LightHunter technology ensures high image quality in low illumination environment.
Experience superior surveillance performance with the Uniview 8MP IP67 Eyeball Camera, featuring LightHunter technology, crystal-clear night vision, and NDAA compliance. Ideal for both residential and commercial security needs.
Key Features of Uniview 8MP Eyeball IP Camera :
- Compression : Ultra 265, H.265, H.264, MJPEG
- Megapixel: 8MP
- Camera Style: Eyeball
- Lens Type :Fixed Lens
- Lens Size : 2.8mm
- Protection Code : IP67
- Dimensions (Ø x H): Φ118 x 95mm (Φ4.6” x 3.8”)
- Weight: 0.36kg (0.79lb)
- Environmental : outdoor
- Audio Support : Built-in Mic
UNV 8MP IP67 Eyeball Camera – LightHunter, NDAA Compliant
The Uniview 8MP IP Camera is a premium-quality UNV IP security camera designed for outdoor environments. Equipped with LightHunter technology, this camera captures ultra-clear images even in low-light conditions, making it a reliable solution for 24/7 surveillance.
This UNV IP camera features a 2.8mm fixed lens and supports advanced video compression formats like Ultra 265, H.265, and H.264 for efficient storage. The IP67 weatherproof rating ensures durability against harsh weather, while the built-in microphone provides real-time audio monitoring.
Perfect for government, business, or home use, this NDAA compliant camera meets strict regulatory standards. Whether you're looking for a Uniview 8MP camera price, Uniview dome camera price, or a trusted POE camera for outdoor use, this model is a top choice among Uniview security cameras.
If you're building a professional-grade system, the Uniview 8MP PTZ camera or Uniview dual lens options pair well with this unit. It's also compatible with ONVIF POE camera systems, ensuring easy integration into your existing setup.
Specification of UNV 8MP Eyeball IP Camera :
Camera |
||||||
| Sensor | 1/2.7", 8.0 megapixel, progressive scan, CMOS | |||||
| Minimum Illumination | Support LightHunter: Colour: 0.005Lux ( F1.6, AGC ON) 0Lux with IR on |
|||||
| Day/Night | IR-cut filter with auto switch (ICR) | |||||
| Shutter | Auto/Manual, 1 ~ 1/100000s | |||||
| Adjustment angle | Pan: 0° to 360°, Tilt: 0° to 80°, Rotate: 0° to 360° | |||||
| S/N | >56dB | |||||
| WDR | 120dB | |||||
Lens |
||||||
| Lens Type | 2.8mm and 4.0mm @1.6, Fixed-focal | |||||
| Lens Mount | M12 | |||||
| Angle of view (H) | 112.9° | |||||
| Angle of View (V) | 59.1° | |||||
| Angle of View (O) | 121.2° | |||||
DORI |
||||||
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) | |
| 2.8mm | 84 | 33.6 | 16.8 | 8.4 | ||
Illuminator |
||||||
| IR Range | Up to 30m (98ft) IR range | |||||
| Wavelength | 850nm | |||||
| IR On/Off Control | Auto/Manual | |||||
Video |
||||||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | |||||
| H.264 code profile | Baseline profile, Main profile, High profile | |||||
| Frame Rate | Main Stream: 8MP Sub Stream: 1080P Third Stream: D1 |
|||||
| Video Bit Rate | 128 Kbps~16 Mbps | |||||
| U-code | Supported | |||||
| 9:16 Corridor Mode | Supported | |||||
| OSD | Up to 4 OSDs | |||||
| Privacy Mask | Up to 4 areas | |||||
| ROI | Up to 8 areas | |||||
| Motion Detection | Up to 4 areas | |||||
Image |
||||||
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | |||||
| Image Setting | Image rotation, brightness, saturation, contrast, sharpness, gain adjustable by web browser | |||||
| Digital noise reduction | 2D/3D DNR | |||||
| Smart IR | Supported | |||||
| Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise | |||||
| Dewarping | N/A | |||||
| HLC | Supported | |||||
| BLC | Supported | |||||
| Defog | Digital Defog | |||||
Events |
||||||
| Basic Detection | Cross line, intrusion(based on human body detection) | |||||
| motion detection, tampering alarm, audio detection | ||||||
| General Function | Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication | |||||
Audio |
||||||
| Audio Compression | G.711 | |||||
| Suppression | Supported | |||||
| Sampling Rate | 8KHZ | |||||
Storage |
||||||
| Edge Storage | Micro SD, up to 256 GB | |||||
| Network Storage | ANR,NAS(NFS) | |||||
Network |
||||||
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, etc. | |||||
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK | |||||
| User/Host | Up to 32 users. 2 user levels: administrator and common user | |||||
| Security | Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF | |||||
| Client | EZStation EZView EZLive |
|||||
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below | |||||
| Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+ | ||||||
Interface |
||||||
| Network | 1 * RJ45 10M/100M Base-TX Ethernet | |||||
| Built-in Mic | Supported | |||||
Certification |
||||||
| EMC | FCC: FCC Part 15 | |||||
| Safety | CE: EN 60950-1 UL: UL60950-1 IEC 60950-1 |
|||||
General |
||||||
| Power | DC 12V±25%, PoE (IEEE 802.3af) | |||||
| Power consumption: Max 4.5W | ||||||
| Power Interface | Ø 5.5mm coaxial power plug | |||||
| Dimensions (Ø x H) | Φ118 x 95mm (Φ4.6” x 3.8”) | |||||
| Weight | 0.36kg (0.79lb) | |||||
| Material | Metal | |||||
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F) | |||||
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F) | |||||
| Surge Protection | 4KV | |||||
| Reset Button | N/A | |||||
| Ingress Protection | Ingression protection: IP67 | |||||
