UNV 8MP HD 16-Ch 1 SATA HD NDAA Uniarch IP Network Uniview Security NVR
UNV 8MP HD 16-Ch 1 SATA HD NDAA Uniarch IP Network Uniview Security NVR
SKU:NVR-116E2
Couldn't load pickup availability
UNV 16-Ch 8MP 1 SATA HDD 16-Ch NVR Uniarch IP Uniview Security Video Recorder
The Uniview 16-Ch New Generation Recorder.
Looking for a reliable and high-performance surveillance solution? The Uniview 8MP 16-Channel NVR security system from Secure IT Global delivers unmatched video clarity, NDAA compliance, and ONVIF PoE support — perfect for homes, businesses, or government facilities.
Key Features of Uniview NVR-116E2 Recorder :
- Support Ultra 265/H.265/H.264 video formats
- 16-channel input
- Up to 8MP resolution recording
- Support 1-ch HDMI, 1-ch VGA
- HDMI and VGA simultaneous output
- 1 SATA HDD up to 6TB
- Support cloud upgrade
- Support Ultra 265/H.265/H.264 video formats
- 16-channel input
- Up to 8MP resolution recording
- Support 1-ch HDMI, 1-ch VGA
- HDMI and VGA simultaneous output
- 1 SATA HDD up to 6TB
- Support cloud upgrade
Uniview 8MP 16-Channel IP Camera NVR System – NDAA Compliant
The Uniview 8MP IP camera system with NVR-116E2 recorder is designed for superior surveillance with support for up to 16 channels and high-definition 8MP video input. This Uniview security camera system offers advanced features including Ultra 265, H.265, and H.264 video compression formats for efficient bandwidth and storage usage.
With its NDAA compliant design, this Uniview IP camera solution meets government security requirements, making it ideal for both public and private sectors. The Uniview NVR-116E2 supports a single SATA HDD up to 6TB, ensuring long-term recording capacity without compromise.
This 16 channel NVR security camera system features both HDMI and VGA outputs for flexible viewing, along with cloud upgrade support and remote monitoring through smartphones or computers. The Uniview dome camera options provide clear, detailed footage—day or night—using advanced IR and LightHunter technology.
Whether you're looking for Uniview 8MP camera price, a reliable UNV IP camera, or full Uniview video surveillance, this solution from Secure IT Global delivers professional-grade performance at a competitive value.
Specification of UNV NVR-116E2 Recorder:
Video/Audio Input | |
IP Video Input | 16-ch |
Network | |
Incoming Bandwidth | 64Mbps |
Outgoing Bandwidth | 32Mbps |
Remote Users | 128 |
Protocols | P2P, UPnP, DHCP |
Video/Audio Output | |
HDMI/VGA Output | VGA: 1024X768@60,1280X720@60,1280X1024@60,1600X1200@60,1920X1080@50, 1920X1080@60 HDMI: 1024X768@60,1280X720@60,1280X1024@60,1600X1200@60,1920X1080@50, 1920X1080@60, 3840X2160@30 |
Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Audio Output | 1-ch, 3.5mm |
Synchronous Playback | 4-ch |
Corridor Mode Screen | 3/4/5/7/9/10/12/16 |
Decoding | |
Decoding format | H.265/H.264 |
Liveview/Playback | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Capability | 1 x 8MP@30, 1 x 5MP@30, 2 x 4MP@30, 4*3MP@20, 4 x 1080p@30, 8 x 720p@30, 16 x D1@25 |
Hard Disk | |
SATA | 1 SATA interface |
Capacity | up to 6TB for each disk |
External Interface | |
Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface |
USB Interface | Rear panel: 2 x USB2.0 |
General | |
Power Supply | 12V DC Power Consumption: ≤3.2 W (without HDD) |
Working Environment | -10°C~+55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing) |
Dimensions (W×D×H) | 255mm × 215mm × 42mm (10.0" × 8.5" × 1.7") |
Weight (without HDD) | ≤1kg (2.2lb) |
