UNV NDAA Audio 32-Ch 12MP PoE 4 SATA HDDs ONVIF Uniview IP Network Security NVR
UNV NDAA Audio 32-Ch 12MP PoE 4 SATA HDDs ONVIF Uniview IP Network Security NVR
SKU:NVR304-32E2-P16
Couldn't load pickup availability
UNV 32-Ch Series 12MP PoE Uniview IP Network Security NVR
Uniview 32-Ch is a new generation NVR System.
Secure IT Global proudly offers the Uniview 32 Channel NVR, a powerful network video recorder designed for modern Uniview surveillance systems. Engineered for large-scale commercial or high-end residential security, this NDAA compliant NVR supports up to 32 channels and delivers crystal-clear 12MP recording. Whether you're looking to upgrade your Unv NVR setup or searching for the best network video recorder price, this unit is a future-ready solution that supports ONVIF camera PoE connectivity and advanced analytics. Trusted for its reliability, the Uniview 32 Channel NVR is ideal for deploying a full-scale video surveillance system using Uniview security cameras that meet the strict NDAA 2025 requirements.
Key Features of the 32-Channel PoE NVR :
- Compression: Ultra 265/H.265/H.264
- Channel:32
- Pre-Installed Storage: No HDD
- Video output:1-ch HDMI, 1-ch VGA
- Max.Recording Resolution:12MP
- Hard drive Ports:4 SATA interfaces
- Max.Storage Capacity:10TB
- Color:Black
Uniview 32-Channel 12MP PoE NVR – NDAA Compliant IP Network Recorder
In the ever-evolving world of video surveillance the Uniview Series 32 Channel stands out as a game-changing solution.
In the realm of security applications IP base surveillance systems have recently become the industry standard.
With support for 32 channels this camera provides expansive coverage for your surveillance needs.
Whether you're securing a large commercial property or a sprawling residential estate this NVR has you covered.
The Uniview delivers with its 4K Ultra HD resolution.
Every detail is captured with remarkable clarity ensuring that you never miss a thing.
Whether you want to connect IP cameras access control systems or alarms this NVR offers compatibility and flexibility.
The intelligent video analytics can deter theft and unauthorized access providing peace of mind for business owners.
Homeowners can monitor their property remotely receive alerts and even check in on pets or loved ones.
This Security Camera is a game changer in the world of video surveillance.
If you need it for commercial, residential, educational or healthcare purposes this NVR delivers on all fronts.
Buy Uniview NVR with Confidence from Secure IT Global :
Video/Audio Input | ||
IP Video Input | 32-ch | |
Two-way Audio Input | 1-ch, RCA | |
Network | ||
Incoming Bandwidth | 320Mbps | |
Outgoing Bandwidth | 320Mbps | |
Remote Users | 128 | |
Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS,DNS,DDNS,SNMP,SMTP,NFS | |
Browser | IE(IE10/11) for Windows Firefox (version 52.0 and above) for Windows Chrome(version 45 and above) for Windows Edge(version 79 and above) for Windows |
|
Video/Audio Output | ||
HDMI/VGA Output | VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz,1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz HDMI: 4K (3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
|
Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
Audio Output | 1-ch, RCA | |
Audio Compression | G.711A, G.711U | |
Synchronous Playback | ||
Live View Display | 1/4/6/8/9/16/25/36 | |
Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 | |
Snapshot | ||
FTP/Schedule/Event Snapshot | ||
Decoding | ||
Decoding Format | Ultra 265, H.265, H.264 | |
Live View/Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
Capability | 1 x 12MP@30, 2 x 4K@30, 5 x 4MP@30, 10 x 1080P@30, 22 x 720P@30, 32 x D1 | |
Hard Disk | ||
SATA | 4 SATA interfaces | |
Capacity | up to 10TB for each HDD | |
eSATA | NA | |
Disk Group | Support | |
RAID | RAID 1,5 | |
Smart | ||
VCA Detection by Camera | Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking | |
VCA Search | Behavior Search, Vehicle Search | |
People Counting | People Flow Counting, Crowd Density Monitoring | |
Smart Intrusion Prevention (SIP), Vehicle Detection by Camera | Total 8-ch | |
General Alarm | ||
General Alarm | Motion, Tampering, Human Body Detection, Video Loss, Input Alarm, Audio Detection | |
Alert Alarm | IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal | |
External Interface | ||
Network Interface | 1 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces | |
USB Interface | Front panel: 1 x USB2.0,Rear panel: 1 x USB3.0 | |
RS232 | NA | |
RS485 | 1 | |
Alarm In | 16-ch | |
Alarm Out | 4-ch | |
PoE | ||
Interface | 16 RJ-45 10M/100M self-adaptive Ethernet Interface | |
Max Power | Max 30W for single port Max 150W in total |
|
Supported Standard | IEEE 802.3af/at | |
General | ||
Power Supply | 100~240V AC Power Consumption: ≤ 20 W (without HDD) |
|
Working Environment | -10°C~+ 55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing) | |
Dimensions (W×D×H) | 400mm × 363mm × 74mm (15.7" × 14.3"× 2.9") | |
Weight (without HDD) | ≤4Kg (8.82lb) | |
Certification | ||
Certification | CE, FCC, UL, RoHS, WEEE | |
CE | EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017 | |
FCC | Part15 Subpart B, ANSI C63.4 |
