UNV 4MP IP67 PoE NDAA Thermal 2-Way Audio 4mm Uniview IP Network Security Camera
UNV 4MP IP67 PoE NDAA Thermal 2-Way Audio 4mm Uniview IP Network Security Camera
SKU:TIC2621SR-F3-4F4AC-VD
Regular price
$2,009.00 USD
Regular price
Sale price
$2,009.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
UNV 4MP IR IP67 PoE NDAA Dual-spectrum Thermal 2-way Audio Bullet Uniview IP Network Security Camera 4mm Fixed Lens with Night Vision
The Uniview Thermal Camera is Dual-spectrum Security surveillance solution.
Features:
Camera Style: Bullet
Megapixel: 4MP
Compression : Ultra 265, H.265, H.264,
Lens Type : Fixed Lens
Lens Size : 4mm
Protection Code : IP67
Working Environment: -40℃~70℃(-40°F ~ 158°F)
Description:
In today's fast-paced world security is a paramount concern for individuals and businesses alike. The need for advanced surveillance solutions has never been greater and one name that consistently stands out in the world of security technology is Uniview. The Uniview is a game-changer in the realm of security cameras. Intelligent analytics is embedded into the camera. Everyone with a basic level of technological expertise may set it up without difficulty with to its user-friendly design. The can be accesses remotely through a secure network connection allowing you to view live footage from anywhere.
Specification:
Thermal Module | |||||
Sensor type | Vanadium Oxide Uncooled Focal Plane Arrays | ||||
Original Resolution | 256*192 | ||||
Field of View(H*V) | 57.0°~42.0° | ||||
Video Resolution | 720P(1280*720), Max 30fps | ||||
IFOV | 3.75mrad | ||||
NETD | ≤55mk @f/1.0 @25°C | ||||
Lens(focal length) | 3.2mm@F1.1 | ||||
Palette | Up to 20 palettes of optional color. |
Optical Module | |||||
Sensor | 1/1.8", 4.0 megapixel, progressive scan, CMOS | ||||
Lens | 4mm@F1.6 | ||||
Iris | Fixed aperture | ||||
Field of View(H*V) | 89.9°~49.1° | ||||
Video Resolution | 4MP(2688*1520), Max 30fps | ||||
Shutter | Auto/Manual, 1 ~ 1/100000s | ||||
WDR | 120dB | ||||
Day/Night | IR-cut filter with auto switch (ICR) | ||||
IR Range | Up to 50m (164 ft) IR range | ||||
Wavelength | 850nm | ||||
IR On/Off Control | Auto/Manual |
Smart (thermal module ) | |||||
Fire Detection | Support the detection of fire point in the environment and up to 10 fire points can be detected | ||||
Smoking Detection | Support the detection of smoking in the environment and link to alarm | ||||
Temperature detection | Support area detection, and link to alarm. Support cold & hot point tracking, timely and clearly shows the abnormal point Up to 12 rules can be set Temperature range: -20°C ~+150°C Temperature accuracy: Max (±8°C/±8%) | ||||
Video | |||||
Compression | Ultra265, H.265, H.264, MJPEG | ||||
Video Stream | Triple streams | ||||
OSD | Up to 8 OSDs | ||||
Privacy Mask | Up to 8 areas per scene | ||||
Audio | |||||
Two-way audio | Supported, Built in mic and speaker | ||||
Sampling Rate | 8kHZ | ||||
Storage | |||||
Edge Storage | Micro SD, up to 256 GB |
Network | |||||
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, | ||||
Compatible Integration | ONVIF (Profile S, Profile G, Profile T) | ||||
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
General | |||||
Power | DC12V(±25%), PoE(IEEE802.3af) | ||||
Power consumption: Max 12W | |||||
Support reverse polarity protection, Overvoltage and overcurrent protection . | |||||
Dimensions (Ø x H) | Φ354mm x 104mm x 116mm | ||||
Weight | 1.85kg(4.08lb) | ||||
Temperature detection working environment | -10°C ~+50°C(-14°F ~ 122°F) | ||||
Working Environment | -40℃~70℃(-40°F ~ 158°F) | ||||
Ingress Protection | IP67 |
